CleanTech Lithium PLC (AIM:CTL, Frankfurt:T2N, OTCQX:CTLHF) an exploration and development company advancing sustainable lithium projects in Chile, announces highly encouraging results from the processing of brine from Laguna Verde at the Company´s Direct Lithium Extraction (DLE) pilot plant in Copiapó, Chile.


The DLE pilot plant has produced high quality eluate with low impuritiesThe performance of the DLE process is based on the composition of the eluate achieving key metrics of:A lithium grade in feed brine of 196mg/L was concentrated to 710mg/L in the eluate, or a 3.6X concentration factorLithium adsorption recovery rate of 94%Rejection rates over 99% for key contaminants calcium, magnesium, potassium, sodium and sulphateA reverse osmosis unit at the DLE pilot plant is used to concentrate the eluate prior to shipment, concentrating the test batch from a lithium grade of 710mg/L in the eluate to 2,194mg/L in the concentrated eluateAn initial 200L of concentrated eluate has been sent to a third-party processor in North America for test work to set up the process plant for conversion of eluate into battery grade lithium carbonateCTL will ship batches of 24m3 of the concentrated eluate for conversion with the first batch scheduled for later this monthThe pilot plant in Copiapó has demonstrated that it can operate at the designed capacity of concentrated eluate production sufficient for conversion to 1 tonne per month of battery grade lithium carbonate

Steve Kesler, Executive Chairman, of CleanTech Lithium PLC, said:

‘The analysis of the eluate shows the DLE performance has exceeded our expectations, concentrating the lithium grade of the feed brine by 3.6X while achieving high recovery rates and low impurities. The first full batch of 24m3 of concentrated eluate is scheduled to be shipped in the coming weeks. The pilot plant has met its design capacity capable of producing 1 tonne of LCE per month, positioning CleanTech Lithium to produce significant quantities of lithium product samples for potential strategic partners. We are edging closer to be one of the first DLE based companies in Chile to produce battery-grade lithium carbonate.’

Further Information

The Company´s DLE pilot plant is in Copiapó, Chile, approximately 250km from Laguna Verde, and finished commissioning in late March. At the R&D centre where the pilot plant is located, brine from the Laguna Verde project is stored in a large 243,000 litre vessel outside the pilot plant and then fed into an indoor tank having passed through filtration to remove suspended solids. It is then fed into the DLE columns shown in Figure 1, which are filled with adsorbent designed to be selective for lithium molecules. Lithium, as lithium chloride, is adsorbed from the brine, before desorption with water to create a purified lithium chloride eluate.

A reverse osmosis (RO) unit at the DLE pilot plant, as shown in Figure 2, then concentrates the eluate by extracting approximately 75% of the water before this concentrated eluate is shipped to the facilities of Conductive Energy in Chicago, USA for conversion into battery grade lithium carbonate. A 200L batch of concentrated eluate was recently air freighted to Conductive Energy for test-work to optimise the planned conversion process before larger volumes of concentrated eluate, which will be shipped in 24m3 containers, are dispatched with the first such shipment scheduled for later this month.

Fig. 1: Pilot Plant Multi-Valve Feeding Brine to DLE Columns (approx. 2.5 metres high)

Fig. 2: Reverse Osmosis Unit Used to Concentrate Eluate at the Pilot Plant

Brine is processed at the DLE pilot plant in cycles where each cycle represents the 30-hour sequence of adsorption, displacement wash and desorption using all 30 of the DLE columns to process the feed brine into eluate. The 200L test batch provides a representative sample taken from the first two DLE cycles completed at the pilot plant. Analysis of the feed brine, eluate and concentrated eluate is provided in Table 1 below.

Element (ions)


Feed Brine


Concentrated Eluate

Boron (B)





Calcium (Ca)





Chloride (Cl)





Lithium (Li)





Magnesium (Mg)





Potassium (K)





Sodium (Na)





Sulphate (SO4)





Total Dissolve Solids (TDS)





Table 1: Composition of Feed Brine, Eluate and Concentrated Eluate (Major Ions)

The concentration of lithium from 197mg/L in the feed brine to 710mg/L in the eluate is 3.6X, which is considered to be a very positive result. DLE primarily acts as a purification stage, recovering lithium chloride from the brine whilst rejecting other impurities. For all the major ions in the brine, apart from boron, the rejection rate was 99% or higher and almost 100% for the largest impurity in the brine which is sodium, as shown in Table 2 below. The adsorbent shows very good selectivity for these ions with extremely high selectivity for lithium to sodium.

The low selectivity for boron is expected with the Company´s process flow sheet, as described in the completed Laguna Verde scoping study, which includes a boron removal stage using ion exchange. The current process flow sheet also includes a nano-filtration stage for magnesium and calcium as a high-level purification of these two elements is required before conversion to battery grade lithium carbonate. The very low levels of these two elements in the eluate indicates nanofiltration may not be required. CleanTech Lithium´s process team is also working on solutions that would reduce or eliminate the requirement for the Boron removal stage to further simplify the process.

Element (ion)

Rejection in Eluate

Boron (B)


Calcium (Ca)


Magnesium (Mg)


Potassium (K)


Sodium (Na)


Sulphate (SO4)


Table 2: DLE Performance – Rejection of Major Impurities

The recovery rate in Cycle 2 was 94% in adsorption with an overall recovery after desorption of 89%. The desorption recovery rate is expected to be further optimised as the pilot plant stabilises over more operational cycles. The production rate achieved was 2.57 kg LCE/hr which meets or exceeds the design capacity of the plant.

Downstream Processing into Battery Grade LithiumCarbonate

For the conversion of the concentrated lithium chloride eluate into battery grade lithium carbonate, CleanTech Lithium has engaged a leading lithium concentration and refining company, Conductive Energy, based in Alberta, Canada, which has a conversion facility in Chicago, USA (see Figure 3). Concentrated eluate will be shipped in batches of 24m3, which corresponds to a shipping container, to the port of Los Angeles before transiting to Chicago.

Figure 3: Conductive Energy – Milling and Refining Equipment, Continuously Stirred Tank Reactor, and Lithium Carbonate product (pictures left to right)

The first step will be to further concentrate the eluate using Forward Osmosis (FO), with the FO unit provided by Forward Water Technology, another Canadian company based in Ontario. FO achieves a high concentration factor with low energy use. Following FO, the conversion process stages undertaken by Conductive Energy, involve polishing by ion exchange to remove trace impurities, carbonation to precipitate lithium carbonate, solid/liquid separation and drying. These standard industry processes for lithium carbonate production are reflective of the conversion process CleanTech Lithium plans to use at a commercial scale for the Laguna Verde project.

Samples of the lithium carbonate product will be analysed by Conductive Energy and a third-party independent laboratory to confirm the benchmark of 99.5% Li2CO3 is achieved for battery grade lithium carbonate. The product will be packaged for shipping to potential strategic partners and off-takers for product verification in the coming months.
